The D-240E Flamed Mahogany features the same full-bodied and powerful tone of the D-240E, but with exotic flamed mahogany back and sides and a solid spruce top for a meaty tone and dynamic response. The dreadnought shape provides guitarists with a classic acoustic sound and balanced voicing, and Guild s historic archback design offers improved bass response and projection. The D-240E also features Guild s AP-1 preamp system for easy control while amplifying your signal for use in stage or studio. Other features include a Pau Ferro fingerboard and bridge, bone nut and saddle, pearloid rosette, tortoiseshell pickguard, and an amber-tinted satin polyurethane finish.

Body

Body Shape        D - Dreadnought

Body Top            Solid Sitka Spruce

Top Bracing Pattern        Scalloped X

Soundhole Diameter      3 7/8" (98mm)

Rosette Mother-Of-Pearl / ABS

Top Purfling Inlay            Black/White/Black ABS

Body Sides          Flame Mahogany

Body Back          Flame Mahogany

Body Binding     Ivory ABS

Neck

Neck Material Mahogany

Scale Length 25 1/2" (648mm)

Neck Shape C Shape

Nut Width 1 11/16" (43mm)

Neck Thickness 1st Fret 20mm

Neck Thickness 9th Fret 24mm

Truss Rod Dual Action

Truss Rod Wrench 4mm Allen Key

Fingerboard Material Pau Ferro

Fingerboard Radius 16" (406mm)

Fingerboard Inlays 5mm Dots - Mother-Of-Pearl

Frets Total 20

Finish

Color Natural (NAT)

Finish Satin Polyurethane

Hardware

Bridge Material Pau Ferro

Bridge String Spacing 2 1/4" (56mm)

Bridge Pins Ivory Colored Plastic with Black Dot

Saddle Material Compensated Bone

Hardware Finish / Plating Nickel

Nut Material Bone

Tuning Machines Guild GBB1 Butterbean Tuning Machines 16:1 Nickel

Endpin  Strap Button Nickel

Pickguard Tortoiseshell

Electronics

Electronics Guild/Fishman Sonitone GT-1 with Volume and Tone controls

Other

Strings D'Addario EXP16 - Coated Phosphor Bronze Light (.012 - .053)

Upper Bout Width 11 5/8" (295mm)

Lower Bout Width 15 3/4" (400mm)

Body Depth Upper Bout 3 3/4" (95mm)

Body Depth Lower Bout 4 3/4" (121mm)

Body Length 19 3/4" (502mm)

Overall Length  42" (1067mm)

Item #   383-0404-921

Model:  D-240-E-FM
Part Number:  GUI-D-240-E-FM
Brand:  Guild
Body Shape  Dreadnought
Electro Acoustic  Yes
Body Material  Spruce
Soundboard  Spruce
Back & Sides  Mahogany
Fingerboard  Rosewood
Neck Material  Mahogany
Scale Length  25.5" (647mm)
Construction  Set Neck
Colour  Natural
Finish  Satin
Number of Strings  6
Type  Acoustic Guitar
