Played on countless hit recordings for decades now, the mid-'60s Deluxe Reverb is a timeless Fender classic and one of the most indispensable workhorse guitar amps ever made. Moderately powered and producing a full, snappy and crystalline tone revered in studios from Muscle Shoals to Abbey Road and on stages worldwide, it's a must-have tone machine. Today, the '65 Deluxe Reverb is still one of the coolest amps around, with the fantastic sound and vintage mid-'60s style still prized by rock, blues and country players everywhere. A classic then and a classic now.
General
SERIES American Vintage
COLOR Black and Silver
AMPLIFIER TYPE Tube
COUNTRY OF ORIGIN US
PLATFORM Pro Tube
Electronics
CONTROLS Normal Channel: Volume, Treble, Bass; Vibrato Channel: Volume, Treble, Bass, Reverb; Vibrato: Speed, Intensity
CONTROL PANEL Normal Channel: Volume, Treble, Bass; Vibrato Channel: Volume, Treble, Bass, Reverb; Vibrato: Speed, Intensity
INPUTS Four - (1/4", Two Normal and Two Vibrato)
CHANNELS Two - (Normal and Vibrato)
EFFECTS LOOP NA
CONNECTION TYPE 1/4"
VOLTAGE 230V UK
WATTAGE 22 Watts
Hardware
CONTROL KNOBS Vintage-Style Skirted Black Plastic
AMPLIFIER COVERING Black Textured Vinyl
CABINET MATERIAL Birch Plywood
GRILLE CLOTH Silver
HANDLE Molded Plastic Strap with Nickel-Plated Caps
AMPLIFIER JEWEL Red Jewel
SPEAKER JACK Two 1/4" Parallel (Internal and External)
FRONT PANEL Black
REVERB TANK 4-Spring, 8 ohm Spring Reverb Unit 4AB3C1B (p/n 0064063049)
REVERB TANK TYPE 4-Spring, 8 ohm Spring Reverb Unit 4AB3C1B (p/n 0064063049)
Speakers
SPEAKERS One - 12" Jensen C12K with Ceramic Magnet
TOTAL IMPEDANCE 8 ohms
Tubes
POWER TUBES 2 x 6V6
PREAMP TUBES 4 x 12AX7, 2 X 12AT7
RECTIFIER Tube (1 x 5AR4)
Measurements
DIMENSIONS 13.00x22.00x27.50 IN
PRODUCT DEPTH 9.5" (24.13 cm)
PRODUCT HEIGHT 17.5" (44.5 cm)
PRODUCT WIDTH 24.5" (62.2 cm)
POWER TUBES 2 x 6V6
Accessories
FOOTSWITCH 2-Button Vintage Style (Reverb On/Off, Vibrato On/Off), P/N: 0994058000 (Included)
