The OF420 Overhead collapsible acoustic travel guitar features a solid sitka top with layered Pau Ferro RW sides/back and collapses to carry-on size of 22*14*9 inches! It assembles in 20 seconds with Journey’s patented detachable neck system that’s guaranteed for life. A full 24.5 inch scale, a versatile 1 3/4 nut width, best-in-class components, and a wedged ergonomic design make this the most enjoyable guitar you’ll ever play! Tri-piezo pickup and a full-featured TSA compliant carry-on backpack included.

Proprietary Body Design:
Stylized 00 body shape
Center sound hole with Pau Ferro rosette
Wedge design for increased volume, comfort and efficiency

Soundboard:
Hand-selected Premium Solid Sitka Spruce

Back and Sides:
Premium layered Pau Ferro

Bracing:
Forward-shifted tapered X-bracing
Compound block for reduced weight and strengthened latch support

Binding and Markings:
MOP logo and position markings
Maple binding

Scale:
24.5 in (622.3 mm)

Finish:
Satin on soundboard, back, and sides

Bridge:
Ovangkol, high break-angle

Tuners:
Grover 18:1

Electronics:

Included JourneyTek under-bridge passive 3-piezo transducer pickup system delivers accurate and clear amplification for any PA system or amp.

Removable Neck Assembly:
Stainless steel load-bearing components
Push-button release latch under neck
Large adjustment knob on back

Neck:
Carbon fiber reinforced traditional C shape with two-way adjustable truss rod
Solid African Mahogany
Deep-slotted bone nut
Neck width at nut: 1 ¾ in (44.5 mm)
Neck width at 12th fret: 2.2 in (56 mm)
14 Frets to body
20 Frets total

Fret Board:
16 inch Radius, Ovangkol
Medium brass fret wire

String Spacing:
2 ¼ in (>57.2mm)
Compensated bone saddle

Guitar Dimensions and Weights:
Weight: 4.4 lbs (2.0kg)
Weight With Case: 7.4 lbs (3.3kg)
Maximum depth: 4.64 in (11.8cm)
Minimum Depth: 3.5 in (8.9 cm)
Body Length: 18 in (45.7cm)
Total Length: 35.5 in (90cm)
Lower Bout Width: 12.5 in (31.8 cm)

Travel Backpack Specifications

Tech Travel Ready:
TSA compliant 14-inch computer compartment for optimal airport security inspection
Easy-access tablet pocket for up to 9.5 inch tablet devices

All- Premium Material Construction:
Extra-durable Ballistic Nylon external case with premium nylon and velour lining
Extra-padded Body compartment with premium velour
Internally-accessible padded neck compartment with premium velour and string slot
Padded string panel with strings positioning tab
Padded Top and Side handles

Extra Compartments for Your Journey:
Internal/externally accessible compartment for accessories
Additional external topside pocket for additional accessories
Additional elastic pockets in computer compartment
Hideaway, reinforced padded backpack straps with padded back

Maximum Case Dimensions: L*W*H: 22*14*9 in ( 55.9*35.5* 22.9 cm)

Model:  OF240
Part Number:  OF240
Brand:  Journey Instruments
Stock Availability  In Stock
Body Shape  Travel
Body Material  Spruce
Soundboard  Solid Spruce
Back & Sides  Pau Ferro
Neck Material  Mahogany
Scale Length  24.5" (622.3 mm)
Colour  Natural
Finish  Satin
Case Supplied  Deluxe Gig Bag
Number of Strings  6
Type  Acoustic Guitar
