The Battalion Bass Preamp and DI is a compact, flexible pedal that delivers powerful tone shaping capabilities in a rugged pedalboard-friendly package. The Battalion is loaded with features that will appeal to tone conscious bass players and includes a four-band equalizer, fully-featured MOSFET distortion section with three signal path options, a compressor, a noise gate and comprehensive I/O.
Four-band EQ tailored specifically for bass guitar. Includes controls for Bass (below 200Hz), Lo Mid (boost/cut at 280Hz Mid (boost/cut at 750Hz) and Treble (boost/cut above 2kHz).The Battalion’s distortion section delivers an awesome array of distorted bass sounds.Distortion section features Level, Blend, Drive and Tone controls plus a dedicated footswitch.Three signal flow modes yield unique tonal variations. Pre EQ, distortion comes before EQ. Post EQ, distortion comes after EQ and Dry EQ, only the dry signal mixed in with the Blend control is affected by the EQCompressor with dedicated pushbutton, amount control and LED adds thump and sustain to your bass soundNoise Gate with adjustable threshold control eliminates noise and hum while preserving your attack and original toneFlexible I/O allows the Battalion to fit perfectly in any bass rig or application

Four-band EQ tailored specifically for bass guitar. Includes controls for Bass (below 200Hz), Lo Mid (boost/cut at 280Hz Mid (boost/cut at 750Hz) and Treble (boost/cut above 2kHz).
¼" input jack includes switchable 10dB pad
Includes a headphone ready ¼" output jack plus a hardwired ¼" dry output jack
Balanced XLR output for use as a DI. The DI features dedicated level, bypass and ground lift controls
All-analog circuitry
EHX 9.6VDC-200mA power supply included
Current Draw: 100mA @ 9VDC
Dimensions in inches: 4.75(w) x 5.75(l) x 2.5(h)
Dimensions in mm: 121(w) x 146(l) x 64(h)

Model:  Battalion
Part Number:  Battalion
Brand:  Electro-Harmonix
