The Pro-Mod Series continues upon Charvel’s storied legacy of innovative excellence in high-performance guitar design, offering the latest technology and top-notch features that modern players need and expect. An ideal instrument for dazzling high-speed playing, the San Dimas Style 1 HH FR M QM boasts scorching sound, exquisite style and grin-inducing playing feel and performance.

The San Dimas Style 1 HH FR M QM features an alder body with quilt maple top and a bolt-on maple neck with a pair of graphite reinforcement rods to resist bending and warping under environmental stresses. The speed neck profile is designed for lightning fast playing and completely unhindered position shifts while the comfortably rolled fingerboard edges provide the broken-in feel of an instrument with plenty of playing miles on it, and plenty more to go. Its 12”-16” compound radius maple fingerboard hosts 22 jumbo frets and black dot inlays, and has a heel-mount truss rod wheel for quick and convenient neck relief tweaks.

High-output Seymour Duncan JB and Seymour Duncan '59 humbucking pickups are directly mounted to the body, cranking out high octane rock ‘n’ roll tone with plenty of sweet overtones. The volume control conceals a push/pull coil split to have even more tonal variations on tap while the no-load tone control operates like a standard tone control from positions one through nine, removing itself from the circuit at position ten for transparent sound, letting the full natural voice of the guitar shine through. Dive to rumbling depths or add a well-placed rising harmonic without sacrificing your tuning with the Floyd Rose 1000 Series double-locking tremolo bridge system.

Designed with style in mind, the San Dimas Style 1 HH FR M QM is available in a variety of striking and elegant finishes, complete with a Charvel neck plate, sealed die-cast tuners and standard strap buttons.

Body Alder

Body Finish Gloss

Body Material Alder

Body Shape San Dimas Style 1

Body Style Solid Body

Body Top Quilt Maple

Fingerboard Material Maple

Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm)

Headstock Licensed Fender Stratocaster

Neck Construction Bolt-On with Graphite Reinforcement

Neck Finish Hand-Rubbed Satin Urethane

Neck Material Maple

Neck Shape Speed Neck with Rolled Fingerboard Edges

Number of Frets 22

Nut Material Floyd Rose 1000 Series Locking

Nut Width 1.6875" (42.86 mm)

Position Inlays Black Dot

String Nut Floyd Rose 1000 Series Locking

Truss Rod Dual-Action with Wheel

Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel

Bridge Floyd Rose 1000 Series Double-Locking Tremolo (Recessed)

Control Knobs Knurled Flat-Top

Hardware Finish Chrome

Neck Plate 4-Bolt Serialized

Pickguard None

Pickup Covers Black

Strap Buttons Standard

String Trees Floyd Rose Retainer Bar

Strings Nickel Plated Steel (.009-.042 Gauges)

Switch Tip Black

Tremolo Arm Floyd Rose 1000 Series Locking

Tuning Machines Charvel-Branded Die-Cast

Bridge Pickup Seymour Duncan JB TB-4

Controls Volume (Push/Pull Coil Split), No-Load Tone

Neck Pickup Seymour Duncan '59 SH-1N

Pickup Configuration HH

Switching 3-Position Blade: Position 1. Bridge Pickup, Position 2. Both Inner Coils, Position 3. Neck Pickup - (Split Engaged) - Position 1. Bridge Outer Coil, Position 2. Both Outer Coils, Position 3. Neck Outer Coil

Model:  2965131599
Part Number:  2965131599
Brand:  Charvel
Stock Availability  In Stock
Body Shape  Strat
Pickup Configuration  H / H
Body Material  Alder
Fingerboard  Maple
Neck Material  Maple
Scale Length  25.5" (647mm)
Construction  Bolt On
Colour  Blue
Finish  Gloss
Case Supplied  -
Number of Strings  6
Type  Electric Guitar
