Charvel turns modern high performance on its head with the new Pro-Mod DK24 HH 2PT CM, a brazen instrument for the progressive guitarist searching for an unparalleled spectrum of sound.
Featuring a sculpted shredder’s cut heel and a scalloped lower back bout for easy upper access to the fingerboard, the alder body in this classic Dinky style is cloaked in a Matte Blue Frost stage-stealing finish.
The bolt-on caramelized maple “speed” neck has graphite reinforcement, silky-smooth hand-rubbed urethane back finish, heel-mount truss rod adjustment wheel and Luminlay side dots. Its 12”-16” compound radius caramelized maple fingerboard features comfortable rolled edges, 24 jumbo frets, pearloid dot inlays and Graph Tech TUSQ XL nut.
Brimming with versatility courtesy of the mini two-way toggle switch for series and parallel, this axe features an HH pickup configuration consisting of a direct mount Custom Seymour Duncan Full Shred SH-10B bridge pickup and direct mount Seymour Duncan Alnico II Pro APH-1N neck pickup. The bridge pickup radiates a crisp top-end with low-end articulation, while the neck pickup has incredible range with soaring highs and silky lows.
Blending sophisticated style with assertive tone, the DK24 HH 2PT CM also offers premium modern features such as a five-way blade pickup switch, Stratocaster-style skirt knobs for the volume (with 500K EVH Bourns low-friction potentiometer) and no-load tone controls, Gotoh Custom 510 recessed tremolo bridge, locking tuners, chrome hardware and more.
Body Alder
Body Finish Satin
Body Material Alder
Body Shape Dinky
Body Style Solid Body
Fingerboard Material Caramelized Maple
Fingerboard Radius 12"-16" Compound Radius (304.8 mm to 406.4 mm)
Headstock Licensed Fender Stratocaster
Neck Construction Bolt-On with Graphite Reinforcement
Neck Finish Hand-Rubbed Urethane
Neck Material Caramelized Maple
Neck Shape Speed Neck with Rolled Fingerboard Edges
Number of Frets 24
Nut Material Graph Tech TUSQ® XL
Nut Width 1.6875" (42.86 mm)
Position Inlays 4mm Pearloid Dot
String Nut Graph Tech TUSQ XL
Truss Rod Dual-Action with Wheel
Truss Rod Nut Heel-Mount Truss Rod Adjustment Wheel
Bridge Gotoh Custom 510 Tremolo
Control Knobs Strat-Style Skirt
Hardware Finish Chrome
Neck Plate None - 4-Bolt Sculpted Heel
Pickguard None
Pickup Covers Flat Parchment
Strap Buttons Standard
String Trees Fender Standard String Guide
Strings Nickel Plated Steel (.009-.042 Gauges)
Switch Tip Parchment
Tremolo Arm Gotoh
Tuning Machines Charvel-Branded Die-Cast Locking
Auxiliary Switching 2-Position Mini Toggle Down/All Series, Up/All Parallel
Bridge Pickup Seymour Duncan Custom Full Shred SH-10B
Controls Volume (500K EVH Bourns Low Friction Pot), No-Load Tone
Neck Pickup Seymour Duncan Alnico II Pro APH-1N
Pickup Configuration HH
Switching 5-Position Blade: Position 1. Bridge Pickup, Position 2. Both Outer Coils, Position 3. Bridge and Neck Pickup, Position 4. Both Inside Coils, Position 5. Neck Pickup
