The Acoustic GiG begins with Carl Martin’s award winning Compressor/Limiter circuit.Individual controls for compression and level allow for simple and easy operation.Next, is the well known and highly respected Vintage Style Echo with controls for level, tone, repeat and tap-tempo, plus the ‘Dotted 8th Note’ switch for the most beautiful musical echo.The Reverb is a new Analogue/Digital Hybrid, tailored after the vintage-style spring reverbs so suitable for guitar. A beautiful, shimmering, yet warm reverb with the added bonus of becoming a more modulation/chorus/reverb texture at higher settings.The Boost simply allows you to cut though the mix with a crystal clean volume increase of up to 15dB for your solos. No change in your tone, and no increased ‘quackiness’ from your piezo pickups!To gain maximum EQ shaping, Carl Martin found it necessary to include a high quality semi parametric EQ which incorporated this section directly from their famous 3 Band Parametric Pre-Amp which allows for the specific shaping of tone from your guitar and pickup.To avoid potential feedback, the Acoustic GiG has a Phase Shift switch.To complete the Acoustic GiG, there is an incorporated a tuner and an overall mute switch.On the back panel are all the needed connections, 1/4” input, unbalanced ¼” output, high quality balanced XLR out with ground lift, an insert section placed right after the boost and before the EQ section, and 9V DC input with a direct DC output if you find the need for an extra pedal.

Input: 1M Ohm
Output 1/4” unbalanced:600 Ohm
Output DI Balanced:200 Ohm
S/N Ratio: 60dB
Compression range:from 1:1 to 1:00
Gain range compressor: +-20dB
Echo time max: 1000 m.sec
Tone Echo: Cut filter (low pass)
Gain Boost max: +12dB
Bass: +-15dB 20-500Hz, 6dB Oct.
Middle: +-15dB 220Hz-5,1kHz, 6dB Oct.
Treble: +15dB 1,5-16kHz, 6dB Oct.
Send impedance loop:200 Ohm
Return impedance: 1M Ohm
Dimensions: 365 (W) x 120 (D) x 60 (H)mm / 14,37” (W) x 4,7” (D) x 2,36” (H)
Weight: 1,25kg / 2,75lbs

Model:  CM-0025
Part Number:  CM-0025
Brand:  Carl Martin
Stock Availability  In Stock
Type  FX
